AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Key Specifications

• Product Type: 6-Channel Multi-Format Streaming Switcher
• SDI Inputs: 4 × 3G-SDI
• HDMI Inputs: 2 × HDMI 2.0
• Additional Inputs: 2 × DVI-I/VGA and 2 × USB-A media-player inputs
• HDMI Input Resolution: Up to UHD 4K60
• SDI Input Resolution: Up to 1080p60
• Processing/Output Resolution: Up to 1080p60
• Program Outputs: 2 × 3G-SDI + 2 × HDMI + 1 × USB-C
• AUX Output: 1 × SDI
• Multiview: 8-Way SDI/HDMI Multiview
• Multiview Layout: Up to 9-window monitoring
• USB-C Streaming: UVC/UAC, uncompressed 1080p60
• Recording: SD Card, up to 1080p60
• Audio: SDI/HDMI/USB embedded audio + XLR/RCA analog inputs
• Keying: Luma Key and Chroma Key
• Layouts: PiP and PoP
• Transitions: Cut, Auto, Mix, Fade and Wipe
• PTZ Control: VISCA and Pelco-D/P
• Tally: Supported
• Network: RJ45 LAN
• Control: RS-422/RS-485
• Operating Systems: Windows, macOS and Linux

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Overview

The AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher is a professional desktop switcher designed for multi-camera production, live streaming, broadcasting, conferences, events and studio workflows. It combines four 3G-SDI inputs with two HDMI 2.0 inputs, while also providing DVI-I/VGA and USB media-player connectivity for additional source flexibility.

The HDMI inputs support UHD 4K up to 60 fps, while the SDI inputs support up to 1080p60. The switcher scales sources for HD program output and provides SDI, HDMI and USB-C program connections.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Price in Kenya

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Full Specifications

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Performance

• Supports six primary video channels.
• Provides 4 × 3G-SDI and 2 × HDMI 2.0 inputs.
• HDMI inputs accept UHD 4K sources up to 60 fps.
• SDI inputs support up to 1080p60.
• Scales mixed sources to HD output.
• Provides SDI and HDMI program outputs.
• USB-C provides uncompressed 1080p60 video and audio capture.
• Supports SD card recording up to 1080p60.
• Provides PiP and PoP layouts.
• Supports Luma and Chroma Key for advanced compositing.
• T-Bar, Auto and Cut controls support fast live switching.
• Mix, Fade and Wipe effects provide additional transition options.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Design and Build Quality

• Desktop professional production design.
• Physical controls provide direct live-switching operation.
• T-Bar provides precise manual switching.
• Multiple video outputs allow flexible studio integration.
• Designed for permanent studio installations as well as event production.
• Suitable for multi-camera broadcast and streaming environments.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Smart Features

• 6-channel multi-format workflow.
• 4K60 HDMI input support.
• 1080p60 SDI support.
• 9-window monitoring layout.
• 8-way multiview through SDI/HDMI.
• USB-C UVC/UAC streaming.
• SD card recording.
• PiP and PoP.
• Luma and Chroma Key.
• PTZ camera control.
• Tally support.
• Multiple transition effects.
• Integrated six-channel audio mixer.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Connectivity

• 4 × 3G-SDI video inputs
• 2 × HDMI 2.0 inputs
• 2 × DVI-I/VGA inputs
• 2 × USB-A media-player inputs
• 2 × 3G-SDI program outputs
• 2 × HDMI program outputs
• 1 × USB-C program/streaming output
• 1 × SDI AUX output
• SDI/HDMI multiview outputs
• 2 × XLR audio inputs
• 2 × RCA audio inputs
• 2 × RCA audio outputs
• 1 × 3.5mm audio output
• RJ45 LAN
• RS-422/RS-485 control
• DB-15 tally interface

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Audio Performance

• Supports embedded SDI audio.
• Supports embedded HDMI audio.
• Supports USB embedded audio.
• Provides two XLR analog audio inputs.
• Provides two RCA analog audio inputs.
• Includes integrated audio mixing.
• Provides RCA and 3.5mm audio outputs.
• Suitable for productions requiring multiple camera and external audio sources.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Streaming and Recording

• USB-C provides plug-and-play UVC/UAC streaming.
• Supports uncompressed 1080p60 video capture.
• Carries embedded audio through the USB-C streaming workflow.
• Compatible with Windows, macOS and Linux.
• Records the program feed to an SD card at up to 1080p60.
• Suitable for OBS, vMix and other computer-based production workflows.
• Supports live production without requiring a separate USB capture device.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Compatibility

• Professional SDI cameras
• HDMI cameras
• Mirrorless cameras with HDMI output
• DSLR cameras with HDMI output
• Professional camcorders
• PTZ cameras
• Computers with HDMI output
• Computers with DVI/VGA output
• USB media players
• Media servers
• SDI monitors
• HDMI monitors
• Projectors
• Streaming computers
• External audio mixers
• SD cards

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Ideal Use Cases

• Multi-camera live production
• Professional live streaming
• Broadcast production
• Church services
• Conferences
• Corporate events
• Education and training
• Webinars
• Live concerts
• House of worship
• Sports production
• Studio production
• Event videography
• YouTube production
• Online broadcasting
• Virtual studio production
• Portable production setups

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Pros & Cons

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher FAQs

1. How many primary video channels does the VS0605U support?
It provides a six-channel workflow with four 3G-SDI inputs and two HDMI 2.0 inputs. Additional DVI-I/VGA and USB-A source connections are also available.

2. Can the VS0605U accept 4K video?
Yes. Its two HDMI 2.0 inputs support UHD 4K up to 60 fps. The switcher then scales sources for HD program output.

3. Does it support 1080p60 streaming?
Yes. USB-C provides UVC/UAC streaming with uncompressed 1080p60 video and audio.

4. Can it record video?
Yes. The VS0605U can record the program feed to an SD card at up to 1080p60.

5. Does it support chroma key?
Yes. It supports both Luma Key and Chroma Key, making it suitable for virtual studios and green-screen production.

6. Does it support PTZ cameras?
Yes. The switcher supports remote PTZ control using VISCA and Pelco-D/P protocols.

7. Does it have an integrated audio mixer?
Yes. It can mix embedded SDI/HDMI/USB audio together with analog XLR and RCA audio sources.

AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher Conclusion

The AVMATRIX VS0605U 6-Channel SDI/HDMI Multi-Format Streaming Switcher is a powerful multi-format production switcher for professional live video workflows. Its combination of 4 × 3G-SDI inputs, 2 × HDMI 2.0 inputs with 4K60 support, DVI/VGA and USB media inputs, USB-C 1080p60 streaming, SD card recording, multiview, keying, PiP/PoP, PTZ control and integrated audio mixing makes it well suited to broadcasting, churches, conferences, events, studios and professional streaming. At KSh 164,200, it offers a comprehensive six-channel HD production platform with strong input flexibility.
