MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Key Features
- 5 × Gigabit Ethernet ports
- 1 × 1.25Gbps SFP port
- Dual-core 880MHz CPU
- 256MB RAM
- 16MB Flash storage
- RouterOS operating system
- Level 4 RouterOS license
- Passive PoE output on Ether5
- Passive and 802.3af/at PoE input
- USB 2.0 Type-A port
- microSD card slot
- Hardware-accelerated IPsec
- Fanless passive cooling
- Compact design
- Suitable for home, office, and professional wired networks
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Introduction
The MikroTik RB760iGS hEX S is a compact wired router designed for users who need reliable Gigabit networking, advanced RouterOS features, and fiber connectivity without built-in Wi-Fi. It provides five Gigabit Ethernet ports and one SFP cage supporting compatible 1.25Gbps SFP modules.
Powered by a dual-core 880MHz MT7621A processor with 256MB of RAM, the hEX S can handle routing, firewall, VPN, VLAN, traffic management, and other advanced networking configurations. It also features passive PoE output on Ether5, USB connectivity, and a microSD slot for additional storage.
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Price in Kenya
| Product | Price |
|---|---|
| MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU | KSh 13,000 |
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Key Specifications
| Feature | Details |
|---|---|
| Model | RB760iGS |
| Product Name | hEX S |
| Product Type | Wired Gigabit Router |
| CPU | MT7621A |
| CPU Cores | 2 |
| CPU Frequency | 880MHz |
| CPU Threads | 4 |
| RAM | 256MB |
| Storage | 16MB Flash |
| Ethernet Ports | 5 × 10/100/1000 Mbps |
| SFP Port | 1 × 1.25Gbps |
| USB | 1 × USB 2.0 Type-A |
| Memory Card | 1 × microSD |
| Operating System | RouterOS |
| RouterOS License | Level 4 |
| PoE Input | Passive / 802.3af/at |
| PoE Output | Passive PoE via Ether5 |
| Cooling | Passive |
| Input Voltage | 12–57V DC |
| Maximum Power Consumption | 24W |
| Dimensions | 113 × 89 × 28 mm |
| Operating Temperature | -40°C to 70°C |
These specifications correspond to the RB760iGS version of the hEX S; MikroTik also introduced a newer hEX S model in 2025, so the exact model code is important when purchasing.
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Performance
The hEX S provides reliable wired routing performance for small and medium-sized network installations.
- Dual-core 880MHz processor handles advanced RouterOS functions
- Five Gigabit Ethernet ports provide fast wired connections
- 1.25Gbps SFP port enables compatible fiber connectivity
- Hardware IPsec acceleration supports VPN applications
- RouterOS provides firewall, routing, VLAN, VPN, and traffic-management features
- 256MB RAM supports multiple network services
- Passive cooling provides quiet operation
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Build Quality & Design
The hEX S features a small, fanless enclosure that is easy to install in compact networking environments.
- Compact 113 × 89 × 28 mm design
- Passive cooling with no cooling fan
- Suitable for desks, cabinets, and network installations
- Wide operating temperature range
- Designed for continuous wired networking
- Compact construction makes it easy to integrate into small network setups
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Connectivity & Compatibility
The router provides both copper Ethernet and SFP connectivity.
- 5 × Gigabit Ethernet ports
- 1 × 1.25Gbps SFP cage
- Passive PoE output through Ether5
- Passive and 802.3af/at PoE input
- USB 2.0 Type-A port
- microSD card slot
- Compatible with suitable SFP modules
- RouterOS supports advanced routing and network management
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Ideal Use Cases
This router is best suited for:
- Small office networks
- Home networks
- Branch offices
- Small business networks
- Fiber internet installations
- VPN deployments
- Wired enterprise networks
- Network laboratories
- Router and firewall installations
- Professional home networking
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Pros and Cons
| Pros | Cons |
|---|---|
| 5 Gigabit Ethernet ports | No built-in Wi-Fi |
| 1.25Gbps SFP port | SFP module may need to be purchased separately |
| Dual-core 880MHz CPU | No 10G SFP+ connectivity |
| 256MB RAM | Advanced RouterOS configuration requires networking knowledge |
| Passive PoE output on Ether5 | PoE output is passive |
| Hardware IPsec acceleration | Limited to Gigabit Ethernet copper ports |
| USB and microSD expansion | Designed primarily for wired networks |
| Compact and fanless | Not ideal for very large networks |
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU FAQs
How many Ethernet ports does the RB760iGS have?
The MikroTik RB760iGS has five 10/100/1000 Mbps Gigabit Ethernet ports.
Does the hEX S have an SFP port?
Yes. The RB760iGS has one SFP cage supporting compatible 1.25Gbps SFP modules.
Does the MikroTik RB760iGS have Wi-Fi?
No. The hEX S is a wired router and does not include built-in wireless connectivity.
What processor does the RB760iGS use?
It uses a dual-core MT7621A processor running at 880MHz.
How much RAM does the hEX S have?
The RB760iGS has 256MB of RAM and 16MB of Flash storage.
Does it support PoE?
Yes. Ether5 can provide passive PoE output, while the router supports passive and 802.3af/at PoE input.
Can it be used with fiber internet?
Yes. The SFP cage can be used with a compatible SFP module for fiber connectivity.
Does it support VPNs?
Yes. RouterOS supports VPN configurations, and the RB760iGS includes hardware-accelerated IPsec support.
MikroTik RB760iGS hEX S 5×Gigabit Ethernet SFP Dual Core 880MHz CPU Conclusion
The MikroTik RB760iGS hEX S is a capable wired router offering five Gigabit Ethernet ports, a 1.25Gbps SFP port, dual-core 880MHz processing, 256MB RAM, RouterOS, USB connectivity, microSD expansion, and passive PoE capabilities. It is well suited to users who need advanced wired routing and fiber connectivity without built-in Wi-Fi.
At KSh 13,000, the MikroTik RB760iGS hEX S offers a practical networking solution for small offices, branch networks, professional home setups, and other wired network environments.
