Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Key Features

• Wi-Fi 5 with 802.11ac Wave 2 technology
• Dual-band 2.4GHz and 5GHz wireless connectivity
• Up to 400Mbps on 2.4GHz and 867Mbps on 5GHz
• 2×2 MIMO with beamforming
• Integrated high-gain omnidirectional antennas
• IP67-rated rugged outdoor enclosure
• One Gigabit Ethernet port
• 802.3af/802.3at Power over Ethernet support
• Supports up to 256 clients
• Up to 32 SSIDs
• Standalone, cnMaestro cloud and on-premises management
• Designed for enterprise, education, hospitality and public Wi-Fi deployments

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Introduction

The Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point is a rugged enterprise wireless solution designed to provide reliable high-speed connectivity in demanding outdoor environments. It uses 802.11ac Wave 2 technology and dual-band wireless connectivity to deliver strong Wi-Fi coverage for campuses, public spaces, hospitality facilities, schools and industrial environments.

The e510 features an IP67-rated enclosure, integrated omnidirectional antennas and Gigabit Ethernet connectivity with PoE support. It can operate as a standalone access point or be centrally managed using Cambium cnMaestro cloud or on-premises management platforms.

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Price in Kenya

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Key Specifications

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Performance

• Dual-band Wi-Fi provides connectivity across both 2.4GHz and 5GHz frequencies.
• The 5GHz radio supports speeds of up to 867Mbps, while the 2.4GHz radio supports up to 400Mbps.
• 2×2 MIMO and beamforming help improve wireless efficiency and coverage.
• Designed to support high-density outdoor deployments with up to 256 clients.
• Automatic channel selection and transmit-power management help optimize wireless performance.
• Fast roaming features support smoother movement between compatible access points.
• Mesh capability allows flexible wireless network deployment.

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Design

• Rugged IP67-rated housing is designed for demanding outdoor conditions.
• Integrated omnidirectional antennas provide broad wireless coverage.
• Supports pole and wall mounting for flexible installation.
• Designed to withstand temperatures from -40°C to +65°C.
• The enclosure supports outdoor deployments where dust, moisture and weather exposure are concerns.
• The unit has a stated wind resistance of up to 224kph.

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Connectivity

• One IEEE Gigabit Ethernet auto-sensing port provides wired network connectivity.
• 802.3af and 802.3at PoE support allows both power and data to be delivered over Ethernet.
• Supports VLANs and advanced network access-control options.
• Guest access features include vouchers, rate limiting and splash pages.
• Supports RADIUS authentication and enterprise security features.
• Can be centrally managed through Cambium cnMaestro Cloud or an on-premises cnMaestro VM.

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Management

• Supports controller-less standalone operation.
• Can be managed through Cambium cnMaestro Cloud.
• Supports on-premises cnMaestro VM management.
• Provides centralized monitoring and configuration for larger deployments.
• AutoPilot functionality can help manage heterogeneous wireless networks.
• Remote management features make it suitable for enterprise and distributed installations.

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Ideal For

• Schools and educational institutions
• University campuses
• Hotels and resorts
• Industrial facilities
• Business campuses
• Public Wi-Fi networks
• Outdoor events and gathering spaces
• Parks and recreational areas
• Hospitality environments
• High-density outdoor wireless deployments
• Enterprise networking installations

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Pros and Cons

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point FAQs

What is the Cambium cnPilot e510 used for?
The cnPilot e510 is designed for reliable outdoor Wi-Fi deployments in locations such as campuses, public spaces, hospitality facilities, schools and industrial environments.

Does the Cambium cnPilot e510 support Wi-Fi 5?
Yes. It supports IEEE 802.11ac Wave 2, commonly known as Wi-Fi 5.

Is the Cambium cnPilot e510 suitable for outdoor use?
Yes. Its IP67-rated enclosure and wide operating-temperature range make it suitable for demanding outdoor environments.

How fast is the Cambium cnPilot e510?
The e510 supports a maximum PHY rate of up to 400Mbps on 2.4GHz and 867Mbps on 5GHz.

How many clients can the Cambium cnPilot e510 support?
The e510 supports up to 256 clients and up to 32 SSIDs according to Cambium's specifications.

Does the Cambium cnPilot e510 support PoE?
Yes. It supports 802.3af and 802.3at Power over Ethernet.

Can the Cambium cnPilot e510 be managed remotely?
Yes. It supports Cambium cnMaestro cloud management as well as on-premises management, in addition to standalone operation.

How much is the Cambium cnPilot e510 in Kenya?
The price provided for this product is KSh 49,000.

Cambium cnPilot e510 Wi-Fi 5 Outdoor Access Point Conclusion

The Cambium cnPilot e510 is a professional outdoor access point designed for organizations that need reliable wireless coverage in demanding environments. Its Wi-Fi 5 Wave 2 technology, dual-band operation, integrated high-gain antennas and support for up to 256 clients make it suitable for medium- and high-density outdoor networks.

At KSh 49,000, the Cambium cnPilot e510 is a strong option for schools, hotels, businesses, campuses and public Wi-Fi projects that require rugged outdoor construction, centralized management and dependable wireless performance.
