Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Key Features

• Ubiquiti UniFi U7 Pro XG

• Model: U7-Pro-XG

• WiFi 7 (802.11be) access point

• Tri-band 2.4 GHz, 5 GHz and 6 GHz

• 6 spatial streams

• 2×2 MIMO on each frequency band

• Up to 5.8 Gbps on 6 GHz

• Up to 4.3 Gbps on 5 GHz

• Up to 688 Mbps on 2.4 GHz

• 10/5/2.5/1 GbE support

• 10 GbE RJ45 uplink

• 802.3at PoE+ powered

• Up to 320 MHz channel width

• Multi-Link Operation (MLO)

• 4096-QAM

• Up to 140 m² coverage

• 300+ connected clients

• Ceiling and wall mounting

• UniFi Network management

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Overview

The Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point is a high-performance tri-band wireless access point designed for modern multi-gigabit networks. It combines WiFi 7, six spatial streams, 6 GHz connectivity and a high-speed 10 GbE uplink, making it suitable for businesses, enterprise networks, high-performance homes and other environments with demanding wireless requirements.

The U7-Pro-XG operates on the 2.4 GHz, 5 GHz and 6 GHz bands, with 2×2 MU-MIMO on each radio. It provides theoretical maximum data rates of up to 688 Mbps on 2.4 GHz, 4.3 Gbps on 5 GHz and 5.8 Gbps on 6 GHz. The 6 GHz radio supports channels up to 320 MHz, while the 5 GHz radio supports up to 240 MHz.

One of its main advantages is its 10 GbE Ethernet uplink, with support for 10/5/2.5/1 GbE connections. This allows the access point to negotiate with compatible network equipment at different Ethernet speeds, providing considerably more wired capacity than standard 1 GbE or 2.5 GbE access points.

The U7-Pro-XG supports WiFi 7 technologies including Multi-Link Operation (MLO), 4096-QAM and wide 320 MHz channels. These technologies can improve throughput, efficiency and responsiveness when paired with compatible WiFi 7 client devices.

The access point supports approximately 140 m² of coverage and 300+ connected clients, although actual wireless coverage and performance depend on building construction, interference, client devices and network configuration.

The U7-Pro-XG can be ceiling or wall mounted and uses PoE+ for power. It integrates with UniFi Network, providing centralized configuration, monitoring and management.

Price in Kenya: KSh 36,500.

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Price

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Specifications

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Wireless Performance Features

• WiFi 7 technology provides improved wireless efficiency, capacity and responsiveness for compatible modern devices.

• Tri-band 2.4 GHz, 5 GHz and 6 GHz connectivity provides access to three wireless bands and additional spectrum through 6 GHz.

• Six spatial streams provide simultaneous wireless capacity across the three radios.

• Up to 5.8 Gbps on 6 GHz provides high theoretical throughput for compatible WiFi 7 clients using suitable 320 MHz channels.

• Up to 4.3 Gbps on 5 GHz provides high-speed connectivity for demanding wireless devices and applications.

• Up to 688 Mbps on 2.4 GHz provides connectivity for devices that benefit from the longer-range characteristics of the 2.4 GHz band.

• 320 MHz channel support on 6 GHz allows compatible WiFi 7 clients to use very wide channels where spectrum conditions permit.

• 4096-QAM increases the amount of data that can be transmitted per symbol under suitable signal conditions.

• Multi-Link Operation (MLO) allows compatible WiFi 7 devices to use multiple wireless links for improved performance and responsiveness.

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Connectivity Features

• 10 GbE RJ45 uplink provides high-speed wired connectivity between the access point and compatible network infrastructure.

• 10/5/2.5/1 GbE support allows the Ethernet interface to operate with compatible network equipment at multiple speeds.

• Multi-gigabit networking provides substantially greater uplink capacity for high-throughput wireless deployments.

• 802.3at PoE+ supplies power and network connectivity through a single Ethernet cable.

• 10 GbE connectivity makes the U7-Pro-XG particularly suitable for networks built around 10 Gigabit switches and high-speed wired backbones.

• UniFi Network integration allows the access point to be centrally configured and monitored alongside other UniFi devices.

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Network Management Features

• UniFi Network management provides centralized configuration, monitoring and administration.

• Wireless client monitoring provides visibility into connected devices and network activity.

• Guest network support allows visitors to use a separate wireless network.

• VLAN support enables logical separation of users, devices and network resources.

• Wireless meshing supports flexible UniFi wireless deployments where appropriate.

• Fast roaming and radio resource management help optimize wireless connectivity across compatible multi-access-point networks.

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Design & Installation Features

• Ceiling-mounted design allows the access point to be positioned centrally for effective wireless coverage.

• Wall mounting support provides an alternative installation method where ceiling installation is not practical.

• Up to 140 m² coverage makes the U7-Pro-XG suitable for offices, homes, classrooms and commercial spaces.

• 300+ client capacity provides substantial wireless capacity for environments with many connected devices.

• PoE+ installation simplifies deployment by carrying power and network connectivity over one Ethernet cable.

• Compact design provides a professional installation suitable for modern business and enterprise environments.

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Applications

• Enterprise WiFi

• Business Networks

• High-Speed Office Networks

• High-Density Wireless Networks

• Data-Intensive Workspaces

• Schools and Universities

• Hotels and Hospitality

• Large Homes

• Conference Rooms

• Retail Stores

• Guest WiFi

• Multi-Access-Point Networks

• 10 GbE Network Infrastructure

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Pros and Cons

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE FAQs

What is the Ubiquiti UniFi U7-Pro-XG used for?

The U7-Pro-XG is designed for high-performance WiFi 7 networks where a high-speed Ethernet uplink and 6 GHz connectivity are required.

Does the U7-Pro-XG support 6 GHz?

Yes. It is a tri-band access point supporting 2.4 GHz, 5 GHz and 6 GHz.

How many spatial streams does the U7-Pro-XG have?

The U7-Pro-XG has six spatial streams, with 2×2 MIMO on each of its three radios.

What Ethernet speeds does the U7-Pro-XG support?

Its Ethernet interface supports 10/5/2.5/1 GbE, with a 10 GbE RJ45 uplink.

How fast is the U7-Pro-XG?

It supports theoretical maximum wireless rates of up to 688 Mbps on 2.4 GHz, 4.3 Gbps on 5 GHz and 5.8 Gbps on 6 GHz.

Does the U7-Pro-XG support 320 MHz channels?

Yes. Its 6 GHz radio supports channels up to 320 MHz.

Does the U7-Pro-XG support MLO?

Yes. The U7-Pro-XG supports Multi-Link Operation (MLO) for compatible WiFi 7 clients.

Does the U7-Pro-XG support PoE+?

Yes. It uses 802.3at PoE+ for power.

Can the U7-Pro-XG be wall mounted?

Yes. It supports ceiling and wall mounting, with a Lite Mount included.

What is the Ubiquiti UniFi U7-Pro-XG price in Kenya?

The listed price is KSh 36,500.

Ubiquiti UniFi U7 Pro XG WiFi 7 Access Point 10GbE Conclusion

The Ubiquiti UniFi U7-Pro-XG WiFi 7 Access Point is a strong choice for networks that need both high-performance wireless connectivity and a high-speed wired backbone. Its 6-stream tri-band WiFi 7 design, 6 GHz support, 10/5/2.5/1 GbE compatibility, 10 GbE RJ45 uplink, 320 MHz channels, MLO and PoE+ make it well suited to business, enterprise and high-performance home networks.
