Ubiquiti PowerBeam M5 400 (PBE-M5-400)

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Overview

The Ubiquiti PowerBeam M5 400 (PBE-M5-400) is a 5 GHz outdoor wireless bridge designed for long-distance Point-to-Point connectivity. It combines a high-gain 25 dBi directional antenna with Ubiquiti airMAX wireless technology, making it suitable for connecting buildings, remote locations and network sites where running physical cabling is difficult. Ubiquiti specifies the PowerBeam M5 400 for 150+ Mbps throughput applications.

The integrated 400 mm dish reflector provides focused wireless transmission and reception, helping establish directional links between two network locations. A pair of compatible PowerBeam units can therefore be deployed to create a wireless bridge between buildings or other sites.

For wired connectivity, the PBE-M5-400 features one Gigabit Ethernet port. The Ethernet connection carries network traffic and also provides power through passive PoE. A 24V, 0.5A Gigabit PoE adapter is included, simplifying installation where suitable power is available.

The device operates in the 5 GHz frequency range, with Ubiquiti listing worldwide support from 5170 to 5875 MHz, subject to regional regulations. Its directional antenna and outdoor construction make it suitable for wireless backhaul, building-to-building links, remote network connectivity and other outdoor wireless bridge applications.

The PowerBeam M5 400 is built for outdoor deployment. Its enclosure uses UV-stabilized polycarbonate, while the included pole-mount hardware allows it to be installed on suitable poles or mounting structures. Ubiquiti specifies operation from -40°C to 70°C and wind survivability of up to 200 km/h.

Price in Kenya: KSh 15,500.

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Price

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Specifications

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Wireless Bridge Features

• 25 dBi directional antenna gain focuses the wireless signal for long-distance outdoor links.

• 150+ Mbps throughput provides suitable capacity for wireless bridging and backhaul applications.

• 5 GHz wireless operation provides a dedicated platform for outdoor network links.

• Directional dish design helps concentrate wireless transmission toward the remote endpoint.

• Point-to-Point connectivity makes it suitable for connecting two buildings or network locations.

• Long-distance wireless bridging can provide network connectivity where laying Ethernet or fiber is impractical.

• Gigabit Ethernet interface provides the wired network connection to the local network equipment.

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Outdoor Installation Features

• Outdoor UV-stabilized enclosure is designed to withstand prolonged outdoor exposure.

• Pole-mount kit included allows the unit to be installed on a suitable pole or mounting structure.

• 200 km/h wind survivability provides durability for demanding outdoor installations.

• -40°C to 70°C operating temperature supports deployment across a wide range of outdoor conditions.

• Signal-strength LEDs assist with antenna alignment during installation.

• Compact integrated dish design combines the radio and reflector into a single wireless bridge unit.

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Power and Connectivity Features

• 1 Gigabit Ethernet port provides wired network connectivity.

• Passive PoE power allows the device to receive power through its Ethernet connection.

• 24V, 0.5A Gigabit PoE adapter is included with the unit.

• 8W maximum power consumption helps keep the wireless bridge relatively power efficient.

• Gigabit Ethernet interface provides sufficient wired capacity for the device's specified wireless throughput.

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Applications

• Point-to-Point Wireless Links

• Building-to-Building Connectivity

• Wireless Network Bridges

• Internet Backhaul

• Remote Site Connectivity

• CCTV Network Backhaul

• Rural Network Connectivity

• Campus Networks

• Business Network Extensions

• Long-Distance Outdoor Wireless Links

• Wireless ISP Infrastructure

• Temporary Network Links

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Pros and Cons

Ubiquiti PowerBeam M5 400 (PBE-M5-400) FAQs

What is the Ubiquiti PowerBeam M5 400 used for?

The PBE-M5-400 is designed for outdoor wireless bridging, particularly Point-to-Point links between buildings, remote sites and network locations.

What frequency does the PowerBeam M5 400 use?

It operates in the 5 GHz frequency range, with worldwide support listed from 5170 to 5875 MHz, subject to applicable regulations.

What is the antenna gain?

The PowerBeam M5 400 has 25 dBi antenna gain.

What throughput does the PBE-M5-400 support?

Ubiquiti specifies 150+ Mbps throughput for the PowerBeam M5 400.

Does it have a Gigabit Ethernet port?

Yes. It has one Gigabit RJ45 Ethernet port.

How is the PowerBeam M5 400 powered?

It uses passive PoE and comes with a 24V, 0.5A Gigabit PoE adapter.

Can it be used to connect two buildings?

Yes. Two compatible wireless bridge units can be configured to create a Point-to-Point link between buildings or other locations.

Is the PowerBeam M5 400 suitable for outdoor use?

Yes. It has a UV-stabilized polycarbonate enclosure and is designed for outdoor operation.

What is the operating temperature range?

The specified operating temperature range is -40°C to 70°C.

Is the PowerBeam M5 400 pole mountable?

Yes. A pole-mount installation system is included.

What is the Ubiquiti PowerBeam M5 400 price in Kenya?

The listed price is KSh 15,500.

Ubiquiti PowerBeam M5 400 (PBE-M5-400) Conclusion

The Ubiquiti PowerBeam M5 400 (PBE-M5-400) is a dedicated outdoor wireless bridge for establishing long-distance 5 GHz network connections. Its 25 dBi directional antenna, 150+ Mbps throughput, Gigabit Ethernet, passive PoE, integrated dish and rugged outdoor construction make it suitable for building-to-building links, wireless backhaul, remote connectivity and other Point-to-Point network applications.
