TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Overview

The TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ is an unmanaged Gigabit Ethernet switch designed for small offices, surveillance systems, and home networks. It features 5 Gigabit RJ45 ports, with 4 IEEE 802.3af/at PoE+ ports capable of delivering both power and data over a single Ethernet cable. With a 65W total PoE budget, 250m Extend Mode, PoE Auto Recovery, and QoS, it is an ideal solution for powering IP cameras, wireless access points, IP phones, and other PoE-enabled devices.

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Key Features

• 5 × 10/100/1000Mbps Gigabit RJ45 ports

• 4 × IEEE 802.3af/at PoE+ ports

• 65W total PoE power budget

• Up to 30W per PoE port

• Gigabit Ethernet performance

• 250m Extend Mode

• PoE Auto Recovery

• 802.1p/DSCP QoS

• IGMP Snooping

• Fanless silent design

• Plug-and-play installation

• Durable desktop metal housing

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ Price in Kenya

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ Specifications Table

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Performance

• Delivers Gigabit networking on all five ports.

• Supplies up to 30W per PoE+ port with a 65W total power budget.

• Extend Mode allows data and power transmission up to 250 metres (10Mbps mode).

• PoE Auto Recovery automatically restarts unresponsive powered devices.

• QoS prioritizes latency-sensitive applications, while IGMP Snooping improves multicast efficiency.

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Build and Design

• Durable metal enclosure.

• Compact desktop form factor.

• Fanless silent operation.

• Efficient passive cooling.

• Designed for continuous operation.

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Connectivity

• TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ features 5 × 10/100/1000Mbps RJ45 Gigabit Ethernet ports.

• Includes 4 IEEE 802.3af/at PoE+ ports for simultaneous power and data transmission.

• Supports Auto Negotiation and Auto MDI/MDIX.

• Compatible with IP cameras, wireless access points, IP phones, and other IEEE 802.3af/at PoE devices.

• Supports Extend Mode, PoE Auto Recovery, QoS, and IGMP Snooping.

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Ideal Use Cases

• CCTV surveillance systems

• Office networking

• Small business networks

• Wireless access point deployment

• VoIP phone installations

• Retail stores

• Hotels

• Schools

• Home networking

• Smart building installations

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – FAQs

1. How many PoE+ ports are available?

It features 4 IEEE 802.3af/at PoE+ ports.

2. What is the maximum PoE power budget?

The switch provides a 65W total PoE budget, with up to 30W per PoE+ port.

3. Does it support Gigabit Ethernet?

Yes. All 5 ports support 10/100/1000Mbps Gigabit Ethernet.

4. Does it require configuration?

No. It is an unmanaged plug-and-play switch requiring no configuration.

5. What is Extend Mode?

Extend Mode increases PoE transmission distance to 250 metres while reducing port speed to 10Mbps.

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Pros and Cons

TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ – Conclusion

The TP-Link TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+ is an excellent networking solution for surveillance systems, small offices, and business environments requiring reliable Gigabit connectivity and PoE power delivery. With four PoE+ ports, a 65W power budget, Extend Mode, PoE Auto Recovery, and silent fanless operation, it offers dependable performance for a wide range of PoE-enabled devices.
