TP-Link CPE 2.4 GHz 300Mbps 12dBi Outdoor CPE – TL-CPE220

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Overview

The TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 is a professional outdoor wireless networking device designed for long-range point-to-point (PtP), point-to-multipoint (PtMP), and outdoor Wi-Fi coverage applications. Operating on the 2.4GHz band with wireless speeds of up to 300Mbps, it features a 12dBi dual-polarized directional MIMO antenna, Pharos MAXtream TDMA technology, dual Fast Ethernet ports, and Passive PoE support for simplified outdoor deployment. It is ideal for ISPs, farms, campuses, warehouses, and remote network connections.

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Key Features

• 2.4GHz 300Mbps Wireless

• Built-in 12dBi Dual-Polarized Directional Antenna

• Qualcomm Atheros 560MHz Processor

• Pharos MAXtream TDMA Technology

• Point-to-Point & Point-to-Multipoint Connectivity

• Up to 13km+ Wireless Transmission

• 2 × 10/100Mbps Shielded Ethernet Ports

• Passive PoE Support

• IPX5 Weatherproof Enclosure

• 15kV ESD Protection

• 6kV Lightning Protection

• Pharos Control Centralized Management

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 Price in Kenya

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 Specifications Table

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Performance

• Wireless throughput of up to 300Mbps.

• Long-range transmission of 13km+ under optimal conditions.

• MAXtream TDMA technology improves throughput, latency, and scalability for outdoor wireless deployments.

• Adjustable transmit power from 0–30dBm for optimized signal performance.

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Build and Design

• Rugged outdoor enclosure with IPX5 weatherproof protection.

• Built-in 12dBi directional antenna.

• Designed to withstand temperatures from -40°C to +70°C.

• Pole-mount installation for outdoor networking.

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Connectivity

• Operates on the 2.4GHz wireless band.

• Features 2 × 10/100Mbps shielded Ethernet ports.

• Supports Passive PoE deployment up to 60 metres.

• Supports AP, Client, Bridge, Repeater, AP Router, and WISP modes.

• Managed centrally through Pharos Control.

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Ideal Use Cases

• Point-to-Point wireless links

• Point-to-Multipoint deployments

• ISP wireless distribution

• Campus networking

• Farm connectivity

• Warehouse networking

• CCTV backhaul

• Outdoor Wi-Fi coverage

• Rural broadband

• Remote building connections

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – FAQs

1. What wireless speed does the TL-CPE220 support?

It supports wireless speeds of up to 300Mbps on the 2.4GHz band.

2. What is the wireless range?

The device is optimized for 13km+ long-range wireless transmission under ideal conditions.

3. Does it support PoE?

Yes. It supports 24V Passive PoE, allowing deployment up to 60 metres using a single Ethernet cable.

4. Is it weatherproof?

Yes. It features an IPX5 weatherproof enclosure with 15kV ESD and 6kV lightning protection.

5. What operating modes are available?

It supports AP, Client, Bridge, Repeater, AP Router, and WISP operating modes.

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Pros and Cons

TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 – Conclusion

The TP-Link CPE 2.4GHz 300Mbps 12dBi Outdoor CPE TL-CPE220 is an excellent choice for long-distance outdoor wireless networking. With a high-gain directional antenna, long-range transmission, Passive PoE, weatherproof construction, and multiple operating modes, it provides a cost-effective solution for ISPs, businesses, farms, and campus networking projects.
