MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Key Features
- 16-core Tilera Tile-GX processor
- 1.2GHz CPU frequency
- 2GB RAM
- 128MB NAND storage
- 12 × 1G SFP ports
- 1 × 10G SFP+ port
- Dual redundant AC power supplies
- 1U rack-mountable design
- RouterOS with Level 6 license
- Color touchscreen LCD
- USB Type-A port
- RJ45 serial console
- MicroSD card slot
- Hardware monitoring
- Designed for high-performance enterprise routing
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Introduction
The MikroTik CCR1016-12S-1S+ is a professional Cloud Core Router designed for enterprise networks, Internet service providers, data centers, and other demanding networking environments. It features 12 SFP ports for Gigabit fiber connectivity and one SFP+ port supporting 10Gbps connectivity.
The router is powered by a 16-core Tilera Tile-GX CPU running at 1.2GHz and includes 2GB of RAM. It runs MikroTik RouterOS with a Level 6 license, providing advanced routing, firewall, VPN, bandwidth management, and other professional networking features
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Price in Kenya
| Product | Price |
|---|---|
| MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage | KSh 112,000 |
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Key Specifications
| Feature | Details |
|---|---|
| Model | CCR1016-12S-1S+ |
| Product Type | Cloud Core Router |
| Architecture | TILE |
| Processor | Tilera Tile-GX |
| CPU Cores | 16 |
| CPU Frequency | 1.2GHz per core |
| RAM | 2GB |
| Storage | 128MB NAND |
| SFP Ports | 12 × 1G SFP |
| SFP+ Port | 1 × 10G SFP+ |
| Operating System | RouterOS |
| RouterOS License | Level 6 |
| Power Supply | 2 × AC redundant |
| AC Input | 100–240V |
| USB | 1 × USB Type-A |
| Console | RJ45 Serial |
| MicroSD | 1 × MicroSD slot |
| Display | Color touchscreen LCD |
| Cooling | 2 fans |
| Maximum Power Consumption | 47.5W |
| Dimensions | 443 × 197 × 44 mm |
| Rack Mount | 1U |
| Operating Temperature | -20°C to 60°C |
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Performance
The CCR1016-12S-1S+ is designed to handle demanding routing workloads and high volumes of network traffic.
- 16-core CPU provides substantial processing capability
- 12 SFP ports support Gigabit fiber connections
- Dedicated SFP+ port provides 10Gbps connectivity
- 2GB RAM supports advanced RouterOS functions
- RouterOS Level 6 provides extensive enterprise networking capabilities
- Suitable for large routing tables and complex network configurations
- Supports firewall, VPN, BGP, OSPF, MPLS, VLAN, and bandwidth-management functions
- Designed for ISP, enterprise, and data-center networking applications
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Build Quality & Design
The CCR1016-12S-1S+ features a professional 1U rack-mount chassis designed for server rooms and network cabinets.
- 443 × 197 × 44 mm chassis
- Standard 1U rack-mount form factor
- Two cooling fans
- Dual AC power supplies for redundancy
- Color touchscreen LCD for device monitoring and management
- RJ45 serial console
- USB Type-A port
- MicroSD slot for additional storage
- Designed for continuous professional operation (mikrotik.com)
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Connectivity & Compatibility
The CCR1016-12S-1S+ is built primarily for high-speed fiber networking.
- 12 × 1G SFP ports
- 1 × 10G SFP+ port
- Supports compatible MikroTik and third-party SFP/SFP+ modules
- One RJ45 SFP-to-Ethernet copper module is included for management connectivity
- RJ45 serial console
- USB Type-A port
- MicroSD card support
- Compatible with RouterOS-based network deployments
- Supports advanced fiber routing and network backbone configurations
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Ideal Use Cases
This Cloud Core Router is best suited for:
- Internet service providers
- Enterprise networks
- Data centers
- Network backbone deployments
- Fiber network infrastructure
- ISP core routing
- Large corporate networks
- BGP routing environments
- MPLS networks
- High-capacity VPN deployments
- Network aggregation
- Professional network laboratories
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Pros and Cons
| Pros | Cons |
|---|---|
| 16-core processor | No built-in Gigabit Ethernet port |
| 12 × 1G SFP ports | SFP modules may need to be purchased separately |
| 10G SFP+ uplink | Older TILE architecture |
| 2GB RAM | No built-in Wi-Fi |
| RouterOS Level 6 | Designed for professional networking |
| Dual redundant power supplies | Higher power consumption than smaller routers |
| 1U rack-mount design | Requires rack or suitable installation space |
| Touchscreen LCD | Advanced configuration requires networking knowledge |
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage FAQs
How many SFP ports does the CCR1016-12S-1S+ have?
It has 12 SFP ports for Gigabit connectivity and one SFP+ port for 10Gbps connectivity
Does the CCR1016-12S-1S+ support 10Gbps?
Yes. It has one dedicated SFP+ port for 10Gbps connectivity. MikroTik notes that this SFP+ interface operates at 10Gbps.
How much RAM does the router have?
The CCR1016-12S-1S+ has 2GB of RAM and 128MB of NAND storage.
Does it have Gigabit Ethernet ports?
The router does not have built-in RJ45 Ethernet ports. It has 12 SFP ports, and an RJ45 SFP-to-Ethernet copper module is included for management connectivity.
Does it have redundant power supplies?
Yes. It has two AC power inputs, allowing redundant power operation. Each power supply accepts 100–240V AC.
What RouterOS license does it use?
The CCR1016-12S-1S+ comes with a Level 6 RouterOS license.
Yes. The router has a 1U rack-mountable chassis measuring 443 × 197 × 44 mm
Does it support a touchscreen display?
Yes. The CCR1016-12S-1S+ includes a color touchscreen LCD for monitoring and device information
MikroTik CCR1016-12S-1S+ Cloud Core Router 1U Rackmount 12×SFP Cage Conclusion
The MikroTik CCR1016-12S-1S+ is a professional Cloud Core Router designed for high-performance fiber-based networking. Its 16-core processor, 2GB RAM, 12 Gigabit SFP ports, dedicated 10G SFP+ port, dual redundant power supplies, RouterOS Level 6 license, and 1U rack-mount design make it well suited for ISPs, enterprises, data centers, and network backbone deployments.
At KSh 112,000, the MikroTik CCR1016-12S-1S+ is a powerful option for organizations requiring a high-density fiber router with extensive routing capabilities and redundant infrastructure.
