Desview R7SIII 7" Ultra-High Bright 1080p Touchscreen Monitor

DESVIEW R7SIII 7" TOUCH SCREEN SDI

Key Specifications

• Product Type: Professional On-Camera Field Monitor
• Screen Size: 7 inches
• Display Type: IPS LCD Touchscreen
• Resolution: 1920 × 1080 Full HD
• Brightness: 2800 nits
• Contrast Ratio: 1000:1
• Aspect Ratio: 16:9
• Viewing Angle: 178° Horizontal / Vertical
• Color Depth: 10-bit (8-bit + 2FRC)
• Color Gamut: 100% DCI-P3
• HDR: HLG and PQ
• HDMI: HDMI 2.0 Input/Output
• SDI: 3G-SDI Input/Output
• 4K Support: Up to UHD 4K 60Hz via HDMI
• LUT Support: Custom 3D LUT via USB-A
• Monitoring Tools: Waveform, vectorscope, histogram, zebra, false color and focus peaking
• Battery: V-Mount
• Power Input: 2-pin LEMO / USB-C
• DC Output: 8V
• Audio: 3.5mm headphone output
• Mounting: 1/4"-20 threads
• Weight: Approximately 400g

DESVIEW R7SIII 7" TOUCH SCREEN SDI Overview

The DESVIEW R7SIII 7" TOUCH SCREEN SDI is a professional field monitor designed for filmmakers, cinematographers, videographers, broadcasters and content creators. It combines a large 7-inch Full HD IPS touchscreen with an extremely bright 2800-nit display, making it suitable for both studio and outdoor production. The R7SIII adds 3G-SDI input/output to its HDMI connectivity, providing greater flexibility for professional camera and broadcast workflows.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Price in Kenya

DESVIEW R7SIII 7" TOUCH SCREEN SDI Full Specifications

Specifications are based on Desview's R7-series information and professional product documentation.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Display Quality

• 7-inch IPS LCD touchscreen.
• Full HD 1920 × 1080 native resolution.
• Extremely bright 2800-nit display for outdoor shooting.
• 100% DCI-P3 color coverage.
• 10-bit color processing provides smoother tonal transitions.
• 1000:1 contrast ratio.
• 178° viewing angle.
• HDR monitoring with HLG and PQ modes.
• Responsive touchscreen controls for quick image adjustments.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Performance

• Supports UHD 4K 60Hz video pass-through through HDMI.
• 3G-SDI input and output provide professional broadcast connectivity.
• HDMI 2.0 input and output allow integration with modern cameras and external recording or monitoring equipment.
• Waveform and vectorscope assist with exposure and color evaluation.
• Histogram, zebra and false-color tools provide additional exposure control.
• Focus peaking helps identify sharp areas during shooting.
• Pixel zoom enables detailed inspection of image areas.
• LUT support allows users to preview different color grades while recording.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Connectivity

• HDMI 2.0 input
• HDMI 2.0 output
• 3G-SDI input
• 3G-SDI output
• USB-A for LUT loading and firmware functions
• 3.5mm headphone output
• USB-C power input
• 2-pin LEMO power connection
• 8V DC camera-accessory output
• V-Mount battery compatibility.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Design & Build Quality

• Professional 7-inch field-monitor design.
• Lightweight approximately 400g body.
• Durable construction with protective corner elements.
• V-Mount battery plate provides secure battery mounting.
• 1/4"-20 mounting threads on the monitor.
• Supplied monitor mount supports flexible positioning.
• Designed for camera rigs, tripods, cages and professional production setups.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Power & Efficiency

• Supports V-Mount battery power.
• USB-C power input provides additional flexibility.
• 2-pin LEMO power input provides a secure professional connection.
• 8V DC output can power compatible camera accessories.
• Multiple power options make the monitor suitable for studio and field production.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Compatibility

• DSLR cameras
• Mirrorless cameras
• Cinema cameras
• Professional camcorders
• Broadcast cameras
• HDMI-equipped cameras
• SDI-equipped cameras
• Camera cages
• Gimbals
• Tripods
• External recorders
• Wireless video transmission systems

DESVIEW R7SIII 7" TOUCH SCREEN SDI Ideal Use

• Professional filmmaking
• Cinematography
• Broadcast production
• Outdoor video production
• Live streaming
• Documentary production
• Commercial filming
• Interviews
• Event videography
• Studio production
• Run-and-gun filmmaking
• Multi-camera production

DESVIEW R7SIII 7" TOUCH SCREEN SDI Pros & Cons

DESVIEW R7SIII 7" TOUCH SCREEN SDI FAQs

1. What is the screen size of the R7SIII?
The R7SIII features a 7-inch IPS touchscreen with a Full HD 1920 × 1080 resolution.

2. How bright is the R7SIII?
It features an extremely bright 2800-nit display, making it suitable for outdoor and bright-location shooting.

3. Does the R7SIII support SDI?
Yes. The R7SIII provides 3G-SDI input and output, in addition to HDMI 2.0 input and output.

4. Can it pass through 4K video?
Yes. The HDMI connections support UHD 4K signals up to 60Hz for pass-through, while the monitor itself displays the image at 1920 × 1080.

5. Does it support LUTs?
Yes. Custom LUTs can be loaded through the USB-A interface for monitoring different color grades.

6. What battery does the R7SIII use?
The R7SIII uses a V-Mount battery system and also supports USB-C and 2-pin LEMO power options.

DESVIEW R7SIII 7" TOUCH SCREEN SDI Conclusion

The DESVIEW R7SIII 7" TOUCH SCREEN SDI is a powerful professional field monitor for filmmakers, broadcasters and content creators who need a large, bright and flexible monitoring solution. Its 7-inch Full HD touchscreen, 2800-nit brightness, 100% DCI-P3 coverage, 10-bit color, 4K 60Hz HDMI pass-through, 3G-SDI connectivity, HDR support and professional monitoring tools make it well suited to demanding production environments. At KSh 42,800, it offers an excellent combination of professional connectivity, outdoor visibility and monitoring functionality.
