DAHUA NVR4232-16P-4KS3 -32CH 1U 16PoE 2HDDs Lite NVREmbedded Linux Operating system
-
Model – Dahua NVR4232‑16P‑4KS3 Lite NVR
-
Channels – 32 IP camera channels
-
PoE ports – 16 PoE ports (IEEE 802.3af/at)
-
Resolution – Up to 8 MP recording per channel
-
Compression – H.265+/H.265/H.264+ encoding
-
Operating system – Embedded Linux
-
Outputs – HDMI and VGA simultaneous video output
-
Storage – 2 SATA HDDs up to 6 TB each
-
Smart features – Motion detection, playback, smart search, AI coding support
-
Network – 1 RJ‑45 port (10/100 Mbps Ethernet)
-
Audio – 1 channel input, 1 channel output
-
Power supply – DC 48 V (PoE integrated)
-
Operating conditions – –10 °C to +55 °C, humidity ≤95%
DAHUA NVR4232-16P-4KS3 -32CH 1U 16PoE 2HDDs Lite NVREmbedded Linux Operating system
The DAHUA NVR4232-16P-4KS3 32-Channel 1U 16-PoE 2-HDD Lite NVR is a powerful network video recorder designed for medium and large-scale IP surveillance installations. Powered by an Embedded Linux operating system, it supports up to 32 IP cameras and features 16 built-in PoE ports for simplified camera deployment. The recorder supports up to 12MP camera resolution, Smart H.265+ video compression, AI-powered Smart Motion Detection (SMD Plus), face recognition, perimeter protection, and remote management through the DMSS mobile application. It is ideal for offices, schools, warehouses, hotels, retail stores, and enterprise security systems.
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Price in Kenya
| Product | Price |
|---|---|
| DAHUA NVR4232-16P-4KS3 32-Channel 1U 16-PoE 2-HDD Lite NVR | KSh 29,500 |
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Key Specifications
| Specification | Details |
|---|---|
| Product Type | 32-Channel PoE Network Video Recorder |
| Model | NVR4232-16P-4KS3 |
| Operating System | Embedded Linux |
| IP Camera Channels | 32 |
| PoE Ports | 16 × IEEE 802.3af/at PoE Ports |
| Maximum Camera Resolution | Up to 12MP |
| Video Compression | Smart H.265+, H.265, Smart H.264+, H.264, MJPEG |
| Incoming Bandwidth | 160 Mbps |
| Storage | 2 SATA HDDs (Up to 20TB per HDD) |
| Network Interface | 1 × Gigabit Ethernet (RJ-45) |
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Design & Build
- Compact 1U rack-mountable design.
- Durable metal enclosure.
- Sixteen integrated PoE ports for plug-and-play installation.
- HDMI and VGA simultaneous display outputs.
- Front and rear USB ports for peripherals and backups.
- Designed for continuous 24/7 surveillance.
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Features and Performance
- Supports up to 32 IP cameras with resolutions up to 12MP.
- Smart H.265+ compression reduces storage and bandwidth usage.
- AI by Recorder supports Smart Motion Detection (SMD Plus).
- AI by Camera supports face detection, face recognition, perimeter protection, people counting, stereo analysis, and heat mapping.
- Provides up to 160 Mbps incoming bandwidth for stable recording.
- Supports EPTZ and one-click arming/disarming for enhanced security management.
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Ideal Use Cases
- Office buildings.
- Shopping malls and retail stores.
- Schools and universities.
- Hotels and hospitality facilities.
- Warehouses and industrial sites.
- Large residential and commercial properties.
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Connectivity and Compatibility
- Supports ONVIF-compliant IP cameras.
- Features 16 built-in PoE ports for direct camera connectivity.
- HDMI and VGA outputs for monitor connection.
- Gigabit Ethernet port for high-speed networking.
- Compatible with Android and iOS through the DMSS app.
- Supports remote configuration, playback, firmware upgrades, and integration with compatible Dahua AI cameras.
DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR Pros and Cons
| Pros | Cons |
|---|---|
| Supports up to 32 IP cameras | Hard drives sold separately |
| Sixteen built-in PoE ports simplify installation | AI features require compatible cameras |
| Dual SATA bays support large storage capacity | |
| Smart H.265+ compression reduces storage usage | |
| Advanced AI analytics and SMD Plus | |
| Remote monitoring through the DMSS app |
FAQs
1. How many cameras does the DAHUA NVR4232-16P-4KS3 support?
It supports up to 32 IP cameras and includes 16 built-in PoE ports for direct connection of compatible cameras.
2. What is the maximum supported camera resolution?
The recorder supports IP cameras with resolutions of up to 12MP, delivering detailed and high-quality video recording.
3. How much storage does the NVR support?
It features 2 SATA HDD bays, with each bay supporting up to 20TB, allowing a maximum storage capacity of 40TB.
4. Does it include AI-powered security features?
Yes. It supports SMD Plus, face detection, face recognition, perimeter protection, people counting, stereo analysis, and heat mapping when paired with compatible AI cameras.
5. Can I monitor the recorder remotely?
Yes. The DMSS mobile application enables live viewing, playback, notifications, and remote management from Android and iOS devices.
6. Is the DAHUA NVR4232-16P-4KS3 32-Channel 16-PoE Lite NVR worth buying?
Yes. With support for 32 IP cameras, 16 integrated PoE ports, 12MP recording, dual HDD bays, Smart H.265+ compression, and advanced AI features, it is an excellent solution for large surveillance installations. At KSh 29,500, it offers outstanding value for commercial and enterprise security systems.
Conclusion
The DAHUA NVR4232-16P-4KS3 32-Channel 1U 16-PoE 2-HDD Lite NVR is a professional-grade network video recorder built for demanding surveillance applications. Its Embedded Linux operating system, support for up to 32 IP cameras, 16 integrated PoE ports, 12MP recording capability, dual HDD support, and intelligent AI analytics make it an ideal choice for businesses, educational institutions, hotels, warehouses, and commercial properties. At KSh 29,500, it provides a scalable, reliable, and future-ready IP surveillance solution.
