DAHUA KTH01-IP Video Intercom Touchscreen Monitor

DAHUA KTH01-IP Video Intercom Touchscreen Monitor

• Display – 7″ TFT capacitive touchscreen, resolution 1024 × 600

• Operating system – Embedded Linux

• Connectivity – Wi‑Fi (IEEE802.11b/g/n, 2.4 GHz), 1 × RJ‑45 10/100 Mbps Ethernet port, Standard PoE support

• Audio – Two‑way audio (half‑duplex with VTO, full‑duplex with app), built‑in speaker, echo suppression, noise reduction

• Video – H.264 decoding, supports video calls, snapshots, and recording (SD card required)

• Storage – MicroSD card slot, up to 64 GB

• Alarm integration – 6 alarm inputs, 1 alarm output, RS‑485 port

• Functions – Unlock, voice call, video call, group call, app management, DND mode, multiple bell sounds, DWDR support

• System capacity – Villa: 9 digital + 2 analog extensions; Apartment: 4 digital + 2 analog extensions

• Power supply – 12 V DC/1A or PoE; consumption ≤3.8 W standby, ≤8.9 W working

• Dimensions – 189.6 × 134.6 × 26 mm (7.46″ × 5.30″ × 1.02″)

• Weight – ~604 g

• Operating conditions – –10 °C to +55 °C, humidity 10%–90%

DAHUA KTH01-IP Video Intercom Touchscreen Monitor

The DAHUA KTH01 IP Video Intercom Touchscreen Monitor is a modern indoor monitoring solution designed to provide secure and convenient visitor communication. Featuring a 7-inch capacitive touchscreen, the monitor supports video calls, voice communication, remote door unlocking, snapshot capture, and mobile app management. It is suitable for homes, apartments, offices, and commercial buildings seeking a reliable IP-based video intercom system.

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Price in Kenya

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Key Specifications

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Design & Build

• Slim and elegant white finish.
• Responsive 7-inch capacitive touchscreen.
• Surface-mounted installation.
• Built-in speaker and microphone.
• Modern interface with touch controls.
• Designed for residential and commercial interiors.

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Features and Performance

• Supports video calling and voice communication.
• Remote door unlocking from the indoor monitor.
• Two-way audio with echo suppression and digital noise reduction.
• Snapshot capture and visitor message recording with an SD card.
• Multiple ringtone options with adjustable volume.
• Supports Do Not Disturb mode and mobile app integration.

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Ideal Use Cases

• Residential homes.
• Apartments.
• Office buildings.
• Hotels.
• Schools.
• Commercial premises.

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Connectivity and Compatibility

• Compatible with Dahua IP video door stations.
• Supports SIP and ONVIF protocols.
• Connects through Ethernet networks.
• Compatible with Dahua mobile app management.
• Supports multiple indoor monitors and door stations.
• Integrates with Dahua access control systems.

DAHUA KTH01 IP Video Intercom Touchscreen Monitor Pros and Cons

FAQs

1. What screen size does the DAHUA KTH01 have?

The monitor features a 7-inch TFT capacitive touchscreen with a 1024 × 600 resolution for clear video communication.

2. Does the DAHUA KTH01 support two-way audio?

Yes. It includes a built-in microphone and speaker with echo suppression and digital noise reduction for clear conversations.

3. Can I unlock the door from the monitor?

Yes. The monitor allows remote door unlocking when connected to a compatible Dahua video door station.

4. Does the monitor support mobile app management?

Yes. It supports app management, allowing users to manage calls and access certain intercom functions remotely.

5. Can the system store visitor snapshots?

Yes. When an SD card is installed, the monitor can save snapshots and visitor messages.

6. Is the DAHUA KTH01 IP Video Intercom Touchscreen Monitor worth buying?

Yes. With its 7-inch touchscreen, two-way audio, remote door unlocking, snapshot recording, and mobile app support, the DAHUA KTH01 is an excellent choice for modern residential and business intercom systems. At KSh 12,500, it offers reliable performance and excellent value.

Conclusion

The DAHUA KTH01 IP Video Intercom Touchscreen Monitor combines a responsive 7-inch touchscreen, high-quality two-way audio, remote door control, visitor recording, and smart app integration into a reliable indoor intercom solution. Whether for homes, apartments, or offices, it enhances security and convenience while delivering dependable performance. At KSh 12,500, it is an excellent investment for modern access control systems.
